1X1 Ceiling light
Product Details:
1X1 Ceiling light Price And Quantity
- 50 Piece
- 1000.00 - 2000.00 INR
- 1000 to 2000 INR
Product Description
Housing Specification
| Body Material | Aluminum |
| Dimension | 300x300mm |
| Weight | 800 gm approx |
| In progress Protection | Ip-20 |
| Cover | Acrylic |
| Gasket | Silicon |
| Accessories | Stainless Steel |
| Paint | Powder Coating |
| Mounting | ‘C’ Clamp |
| Power Cord | 1mm triple shield wire |
| Cerficate | CE, RoHS, BIS, FCC,BEE |
Technical Specification
| Voltage Range | 90V-270V AC |
| Power Consumption | As per sheet below |
| PF | >0.95 |
| THD | <10% |
| Phase type | Single phase |
| Internal wiring | Teflon |
| Input wire | 3 Core (Red Phase, Black Neutral, Green Ground) |
| Frequency | 50Hz-60Hz |
| Efficiency | >85% |
| Illuminance Design | LED + Reflector |
| Storage Temperature | -25°C ~ +65°C(Best 25°C) |
Lighting Specification
| Available wattages | 15, 20, 30 |
| No. of LEDs | 15, 20, 30 |
| Lumens Output (Datasheet) | 145 lumens/Watts |
| Color Temperature | 2700~7000k(Optional) |
| Beam Angle | 120° |
| CRI | >80 Ra |
| Operating Temp. | -40°C to 60°C |
| Life Span | >50000H |
