Electra Mini LED Flood Light
Product Details:
Electra Mini LED Flood Light Price And Quantity
- 3000 to 5000 INR/Piece
- 3000.00 - 5000.00 INR/Piece
- 3000 to 5000 Piece
Product Description
Housing Specification
Body Material | Aluminum |
Dimension | 227x188x105mm |
Weight | 2.3 Kg |
Ingress Protection | IP-65 |
Cover | Toughened Glass |
Gasket | Silicon |
Accessories | Stainless Steel |
Paint | Powder Coating |
Mounting | ‘C’ Clamp |
Power | Cord 1 mm2 triple shield wire |
Certificate | CE, RoHS, BIS, FCC, BEE |
Technical Specifications
Voltage Range | 90V-290V AC |
Power Consumption | As per sheet below |
PF | >0.95 |
THD | <10% |
Phase type | Single phase |
Internal wiring | Teflon |
Input wire | 3 Core (Red Phase, Black Neutral, Green Ground) |
Frequency | 50Hz-60Hz |
Efficiency | >85% |
Illuminance Design | LED + Reflector |
Storage Temperature | -25°C ~ +65°C(Best 25°C) |
Lighting Specifications
Available wattages | 35, 40, 60 |
No. of LEDs | 30, 40, 60 |
Lumens Output (Data sheet) | 145lumens/Watts |
Color Temperature | 2800~6500k(optional) |
Beam Angle | 120° |
CRI | >80 Ra |
Operating Temp. | -40°C to 60°C |
Life Span | >50000H |
